5000L Commercial Brew Kettle Beer Brewing Equipment Price is commercial brewery that is focus on regional market. The capacity request is not so high than micro breweries. Their beers are always sold on shelf in bottle or canning.
  • BME-5000L

  • Brewman

  • 8438400000

Availability:

Product Description

5000L Commercial Brew Kettle Beer Brewing Equipment Price


5000L commercial brewery equipment Introduction:

5000L Commercial Brew Kettle Beer Brewing Equipment Price is commercial brewery

that is focus on regional market. The capacity request is not so high than micro breweries.

Their beers are always sold on shelf in bottle or canning.

4 vessels brewhouse includs Mash tun, Lauter tun, Kettle tun and Whirlpool tun.

This design is mostly used for large commercial breweries to do continuous brew per day.

The complete setup of these breweries is in compliance with modern brewery standards and specifications.

These products enable systematic execution of milling, mashing, fermentation, filtration, filling

and other related processes.

We subject each brewing system to stringent testing procedures before launching them in the market.



Work Process for four vessels best commercial brewing equipment:

Mashing is the process of combining the milled grain and hot water, heating this mixture to different

 temperatures to achieve step mashing in a vessel called a "mash tun".

We get mash after step mashing. The mash will be pumped to lauter tank to process mash lautering

until the wort is clear.

After lautering, the clear wort will be transferred to Kettle tun for wort boiling and hop adding.

After 1-1.5 hour wort boiling, the wort will be pumped to Whirlpool tank for whirlpooling,

forcing the denser solids (coagulated proteins, vegetable matter from hops) into a cone

in the center of the Whirlpool tank. After Whirlpooling, wort will be cooled immediately

by heat exchanger and go to fermenter for fermentation.



5000l commercial brewery setup Shipping:

.Plastic film wrapped and iron frame fixing for FCL(full container loading)

20’GP, 20’HQ, 40’GP, 40’HQ,45’GP,45’HQ,
.Wooden case package for LCL(less container loading) and flat shipping



5000l commercial brewing equipment prices Configuration:

General specification for 5000l commercial brewing kettle

No.

Name

Components

Capacity

Specification

1

Grain Milling Unit

Rolling Miller

2000kg/hr

Double roller

Power:1.5Kw

Noise:45±3db

2

Brewhouse Unit

Mash tun

5000L

Grist hydrator

Agitator with VFD

Lauter tun

5000L

Side mounted grain outdoor with grain chute

Laser cutting V-wire False Bottom

Kettle tun

5000L

Steam condenser/exhaust pipe

Sanitary leveling sight glass

Whirlpool Tun

5000L

Tangential whirlpool inlet

Sanitary leveling sight glass

Hot water tank

10000L

Sanitary leveling sight glass

Yeast feeder

100L

Tri clamp aeration port with ball valve

Heat exchanger

50M2(Effective area)

Completely 304 SS Corrugated plates

YUY pump

10M3x4PCS

ABB, Sanitary SUS304, VFD control

Pipe and fittings

As design

completely SS304, Work Platform is included

3

Fermentation unit

Fermenter

10000L

Dimple cooling jacket on cone and bottom

Side manway

Tri clamp CIP ball

60 degree cone bottom

Perlick style full sanitary sampling valve

Carbonation port and level tube for special request

4

Filtration unit(optional)

Kieselguhr Filter

 2000kg/hr

Power: 2.5kw

Filter Area: 2.4M2

SUS304

5

Bright beer tank

Bright beer tank

10000L

Dimple cooling jacket on cone and bottom

Level tube for checking

Tri clamp CIP ball

Side manway

Perlick style full sanitary sampling valve

Carbonation port with tri clmap carbonation stone

6

Glycol Chilling Unit

Glycol Water Tank

10000L

Insulated conical top and sloped bottom

Chiller

20HPx2PCS

Cooling Capacity: 15400Kcal/8HP

Installed Power:7.8kw

Refrigerant: Freon R404A ,R410A

Noise:70-80db

Coperland compressor

PVC pipe

As designed

Solenoid valves for glycol inlet to tanks are included

Glycol water pump

10M3x2PCS

Sanitary SUS304, VFD control

7

Control unit

Brewing and fermetation process Controlling

Floor type

PLC control with touch screen for special

PC or  mobile remote control for special request

8

CIP

Caustic Tank

500L

electric heating element inside, With bimetal thermometer

Sterilization Tank

500L

H2O2

Pump

3M3

YUY, VFD control

9

Keg cleaning

Double Station Keg Rinser

40-60kegs/hr

Heating: Electric, Power: 15kw(steam  for optional)

10

Keg filling

Single Station Keg Filler

30-40kegs/hr

Input Power: 0.1 kw

11

Bottling line

8 heads

400-500 bottles/hr

Manual

12

Others

Option

Can be Customized

Auger System

Grain Case

Grist Hydrator

Piping flow panel for Brewhouse

Brewhouse Separate PLC Controller
