Japan 300L Micro Electric Brewing System

Views: 0     Author: Brewman     Publish Time: 2024-03-19      Origin: Site

Japan 300L Micro Electric Brewing System

This 300l Combined 3 Vessels Brewhouse Beer Brewery Equipment  is located at NANKOKU-SHI,Japan.

The owner Yuki are very professional in beer brewing, he have many years brewing experience.

It is very lucky for us to have a chance to built their 300l brewery in 2023.

Please review this project with Brewman and share with us your ideas and suggestions.

Part I: Brewery Equipment Commercial starting consulting, proposal communication via email and call.

During this process, we confirm the specification and configuration of 800l Beer Brewery Equipment:

The main configurations mainly include:

1 x 150Kg/h Malt Miller (Stainless Steel 304) ABB motor

1 x 300L Combined 3Vessels Brewhouse (300L Mash/Lauter tank & 300L Hot water tank+ 300L Kettle/Whirlpool tank)

4 x 300L Fermentation Unitank

1 x Brewhouse Controlling Panel

1 x Fermentation Controlling Panel

1 x Steam Supply System

1 x 50L CIP Cart Unit

Part II: 300L Brewery Equipment layout, 2D and 3D drawing design before manufacturing

2D floor plan of 2 barrel brew system

Floor plan of 300l brewing system

3D floor plan for checking the space, the space is very limit

3D floor plan of 300l brew system

3D drawing of brewhouse for pipeline connection

3D drawing of 300l brew system

Part III: Manufacturing of  300l beer brew system

Combined 3 vessels 300l brewhouse (300l hot water tank)

300l brew system

300L Mash lauter tank(on top)& hot water tank(at bottom)

300l mash tun lauter tun hot water tank

Steam pipelines including safty components, steam soleniod valves, steam trap and filter ect.

Steam pipeline for brew systems

Stairs of 300l micro brew system

beer brew system 300l

300l fermenters tank

300l conical fermenter

Part IV: Finish of 2 barrel brew system

300l beer fermenters tank

dry hop port on 300l fermenter

unitanks 300l

300L Mash lauter tank &300L Hot water tank Sparging

300l mash tun lauter tun hot water tank300l brew system

50L CIP Cart Unit

50L CIP Cart Unit

Hop lift on dry hop port cap

Hook on dry hop port

Brewhouse Controller for 300l brew systems

Brew controller

Part V: Shipping of  300l beer brew systems

Two container is required from customers. As the bank will release the left payment after 300l brewhouse in site.

300l brewhouse is loaded and shipped in three 20feet container.

Finish of 300l brewery loading

Part IV: 300l brew systems  arrive at Japan

Part IV: 300l automated brew systeminstalltion

Part V: Expect to their first batch beer.

In Cans

If you also want to realize your brewing dream, come and visit Brewman factory.

Thanks and welcome your inquiry.
