Product Description
PET Bottle Washer And Filler Machine for Sale
| CFA-10-3-PET BOTTLE WASHER AND FILLER | ||||
| Dimension: | PET Washer: | 1.20*0.40*0.70M | ||
| PET Filler: | 0.70*0.50*1.80M | |||
| Capacity： | 180pcs/h | |||
| Power： | According to user local power (110-230V 50/60Hz Single Phase ) | |||
| Power port： | 1P+N+G | |||
| Power consumption： | 2.0-3.5KW | |||
| Main Material： | SUS304 | |||
| AirRegulator： | 0.15-0.20Mpa（22-30PSI） 1.5" Tir-clamp | |||
| Beer Source Pressure： | 0.15-0.20Mpa（22-30PSI） 1.5" Tir-clamp | |||
| Compressed Air： | 0.55-0.80Mpa（85-115PSI） OD:Ф10mm | |||
| CO2 Regulator： | 0.3-0.4Mpa（45-60PSI） OD:Ф10mm | |||
| Time setting way： | Siemens PLC 200 smart | |||
| Connect type： | 1.5" Tri-cleamp | |||
| beer bottle type： | PET bottle and glass bottles with 28mm bottle neck diameter | |||
Filling Part With Flowmeter Or Not： | No | |||
with the residual liquid detection or not: | No | |||
| Wheels or feet | Feet | |||
| Working process: | Product description: Washing process: lock the bottle→washing→finish Filling process: press→CO2 purge→back pressure →Isobaric filling→steady pressure→exhaust→finish | |||
