Packaging is putting the beer into the containers in which it will leave the brewery.

Typically, this means putting the beer into bottles, aluminium cans and kegs/casks,

 it may include putting the beer into bulk tanks for high-volume customers.

keg package is popular among restaurants, BBQ and hotel during summer.

Availability:

Product Description

Combined Keg Filling and Washing Machine for Sale


Two in one keg washer and filler introduction:

Packaging is putting the beer into the containers in which it will leave the brewery.

Typically, this means putting the beer into bottles, aluminium cans and kegs/casks,

 it may include putting the beer into bulk tanks for high-volume customers.

keg package is popular among restaurants, BBQ and hotel during summer.


The combined two in one machine includes both keg washing and filling.

All procedures are thoroughly controlled by SIEMENS programmable controller.

All parameters(time values) can be adjusted without stopping machine.

The machine possesses the cleaning capacity of itself with simple procedures

of cleaning and killing harmful microorganisms.

The machine adopts anoxybiotic technique to guarantee purity and fresh taste of beer.


Specification for Keg washer and filler machine:

Keg washer and filler machine

Dimension: 1.50X1.51X2.15M
Weight: 246KG
with slide or not: No
Packing Size: 1.70X1.65X2.29M
Gross Weight: 425KG
Capacity: Washing part:15-20pcs/h Filling part:40-50pcs/h
Power: According to user local power (3 Phases 380V 50Hz)
Power port: 3P+N+G
Heater way : Steam Coiler Electrical Heater
Power consumption: 2.0KW 14.0KW
Main Material: SUS304

Water tank material

and volume:

 Single tank / Volume=100L

(2pcs)

Motor type and brand: US304 Pump Head
Temperature prode: NTC
Temperature  control mode: STC-200
Time setting way: Siemens PLC 200 smart
Connect type: 1.5" Tri-clamp
Spear type: A, D, S, M, G
Keg type: EURO DIN AMERICAN 20L-60Lkeg
Filling measurement type:  Flow Switch

Washing part inlet with

pressure detection or not

No

Washing part outlet with

the residual liquid detection

or not

No
Washing working procedure:

Lock down → air purge/drain off  →hot water washing→

air purge/drain off→ caustic washing → air purge/to caustic tank

→ hot water 1 washing →air purge/drain off→ hot water 2 washing

 →steam drain hot water→steam sterilized →steam keep pressure sterilized

→CO2 purge/drain off→CO2 fill

Filling working procedure:

Lock down → Sterilize → CO2 purge/drain off→open spear→ CO2 fill

→ fill → close spear →hot water rinse → CO2 purge/drain off

keg filler washer
